ASCENDO CCM10P On-Wall Compact Coaxial Cinema Speaker
Product Description
When space is tight but performance can't be compromised, the ASCENDO CCM10P stands out. This compact two-way passive loudspeaker system features a 10β time-coherent point-source coaxial driver, delivering a full soundstage from a sleek, wall-mounted design.
What sets the CCM10P apart is its remarkable efficiency at 97 dB / 1 W/m and its ability to handle up to 500W. This means you'll enjoy powerful sound levels, hitting a peak of 130 dB, without needing massive amplification. Itβs perfect for living room setups where aesthetics are as important as performance, or as part of a high-performance home theater system.
The CCM10P is designed with versatility in mind, featuring 4-conductor Phoenix 12 AWG input for seamless integration. Plus, its internally braced MDF enclosure and VESA mounting points ensure both durability and easy installation. Whether you're mounting them horizontally or vertically, these speakers are a sophisticated addition to any room.
For a truly immersive experience, pair the CCM10P with our ASCENDO subwoofers and witness the transformation of your audio environment. Visit our Houston showroom or schedule a consultation across Texas to experience these speakers firsthand. Our professional installation and calibration services ensure your system performs at its best.
| Speaker Type | 10β time-coherent point-source coaxial |
| Principle | Vented Passive |
| Woofer | 10β woofer |
| Tweeter | 1 β β voice coil diameter, compression driver |
| Recommended ASCENDO Amplifiers | AIA2-1404, AIA2-2704, AIA4-2404, AIA8-2704, AIA8-6004 |
| SPL (Half Space 2pi) | 120 dB (Cont.) / 130 dB (Peak) |
| Frequency Range | 100 Hz - 20 kHz / -3 dB |
| Power Handling | 500 W |
| Efficiency | 97 dB / 1 W/m 2 pi |
| Impedance | 8 Ξ© |
| Directivity | Horizontal x Vertical in degΒ° 85Β° x 85Β° |
| Input Terminal | 4-conductor Phoenix 12 AWG (3.3 mmΒ²) |
| Dimensions (W/H/D) mm | 300 | 500 | 145 (Without Grille) |
| Dimensions (W/H/D) inch | 11 13/16 | 19 11/16 | 5 11/16 (Without Grille) |
| Weight | 26.46 lbs | 12.0 kg |
| Gross Weight | 30.86 lbs | 14.0 kg |
| Enclosure | Internally braced MDF |
| Finish | Matte black / White glossy |
| Mounting | 4 x wall brackets for horizontal and vertical installation + VESA 100 x 100 mounting points |
